Cat® ELI and ELC
Learn More
Cat® ELI™
Cat® ELI™ (Extended Life Inhibitor) is a long-lasting coolant for industrial engines working in non-freezing environments. Cat ELI uses an active protection technology, similar to Cat ELC, that avoids the problems experienced with conventional coolants and supplemental coolant additives (SCA) mixed with water. The organic additives in Cat ELI specifically target the cooling system surfaces that are susceptible to corrosion, delivering superior protection, improved cooling system efficiency, and reduced environmental impact.
BENEFITS OF CAT ELI
Lowers your cost
Lasts 3-6 times longer than regular coolants, cutting maintenance costs with fewer checks and inhibitor replacements, and minimizing coolant drains/flushes.
Lowers your downtime and repair cost
Superior corrosion protection and effective heat transfer.
Superior protection for your coolant system
Protects aluminum, brass, copper, iron, steel, etc. from pitting and corrosion.
Lower impact on the environment
No glycol in the formula.
Shop for Cat® ELI options here:
Up to Six Times the Life
The protection provided by Cat ELI lasts three to six times longer than that offered by conventional coolants.
| Typical Characteristics1 | ||
|---|---|---|
| ASTM Performance Requirements2 | ASTM D1384, D2570, D4340 | |
| Colour | Red | |
| Recommended Dilution Level3 | 7.5 % | |
| Freeze Protection | ||
| Cat ELI does not provide freeze protection | ||
| pH (7.5% solution) | 8.5 | |
| Nitrite (7.5% solution) | 500 ppm | |
| Molybdate (7.5% solution) | 530 ppm | |
| Boiling protection at sea level | 100°C, 121°C with 1 bar (15psi) pressure cap | |
1The values shown are typical values and should not be used as quality control parameters to either accept or reject product. Specifications are subject to change without notice.
2Exceeds performance requirements for automotive and heavy-duty coolants as specified by ASTM D3306, D4985, D6210.
3ELI concentration can be determined using a Brix refractometer, part number 360-0774.
Cat® ELC
Cat® ELC (extended life coolant) incorporates an advanced technology with organic acid corrosion inhibitors for maximum copper, solder, brass, steel, cast iron, and aluminum protection.
BENEFITS OF CAT ELC
Designed and formulated to exceed industry standards
Protect against boiling and freezing
Provide industry-leading corrosion resistance
Help extend engine life
Ensure the best performance for Cat equipment
Provide the lowest total cost of ownership when used with Cat filters and Cat S•O•S™
Shop for Cat® ELC options here:
Cat ELC for Maximum Coolant Life
