Cat® Ground Engaging Tools (GET)
Learn More
Cat® Ground Engaging Tools Cat Cutting-Edge Systems for Track-Type Tractors D3, D4, D5, D6, D7, D8, D10, D11
THE BEST VALUE AND COST PER HOUR FOR YOUR CAT EQUIPMENT
Cat track-type tractor cutting edges and end bits are designed to create a balance with your machine––and your conditions. All Cat cutting edge systems make sure you move more material longer with less downtime for lower cost per hour. Choose the features you need to match your application and get the results you want.
CATERPILLAR WARRANTY
Cat end bits and cutting edges are guaranteed against breakage. If a component breaks during normal operation, it will be replaced free. The warranty is subject to certain terms and conditions.
THE BEST VALUE AND COST PER HOUR FOR YOUR CAT EQUIPMENT
Features |
Benefts |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
THE ADVANTAGE OF CHOICES
Our extensive range of ground engaging tools (GET) means your cutting edges and end bits will be matched to your equipment for higher performance, lower cost, and abrasion resistance. Each system is designed to help improve the performance of your machines.
D3, D4, D5 Cat Precision Cutting Edges
*Compared to legacy cutting edges
D6, D7, D8 Equipped with Semi-U (SU) Blade, Cat FirstcutTM Cutting Edge System
This system penetrates easier, loads faster, and increases productivity with precision blade control that slices through the toughest materials. Cat FIRSTCUTTM cutting edges are designed for your most demanding applications, with up to 35% increase in payload mass and 17% greater productivity over standard production cutting edges.
D10, D11 Cat High Abrasion Cast Cutting Edge System
The new Cat High Abrasion Cast Cutting Edge System maximizes machine uptime in the most abrasive applications and delivers reduced machine downtime and higher productivity. The new high abrasion end bits are now complemented by cast high abrasion cutting edges for up to 40% longer wear life than Extended Wear Life.
A SYSTEM THAT MAKES SENSE WITH SUPPORT YOU CAN COUNT ON
Take full advantage of Cat dozer edge systems––equip your machines for improved performance and service life. We are available with the parts and knowledge to support your specific needs for cutting edges and end bits. We will:
Identify signs of premature wear and suggest corrective action
Suggest operating techniques to reduce wear
Explain how other manufacturers’ components could damage moldboards
Offer other blade protection products such as: weld-on half arrows, pin-on side-bar protectors, and wear plates
Help determine the best combination of components for your application to improve your cost per hour
IT IS EXTREMELY IMPORTANT TO KEEP ALL HARDWARE TIGHT
- Use new bolts and nuts when installing new end bits and cutting edges to ensure against metal fatigue
- Surfaces must be clean of dirt, paint, scale, rust, and weld splatter
- Mating surfaces must be clean and flat to assure maximum clamping force
- Bolt and nut threads must be clean; do not apply lubricant to the hardware, as this may over-stretch the bolt
- Cutting-edge bolts are installed from the center outward or from one end to the other
- End-bit bolts are installed first from the center outward, then from the center inward
- Tighten all bolts to the required torque
- Seat bolt heads in the countersinks with a heavy hammer
- Tighten the bolts again to required torque
Speak With Us And Find Out More about Cat Cutting-Edge Systems.
Because at Tractors Singapore, we ensure that you get the best advice and service from our highly skilled dealer specialist to keep your equipment performing at its best.
